KDP Honda C-Class Ultra 7X Interchangeable Marine Propeller Rubber Hub Kit (Aluminum Alloy) - Solas RBX-113, Michigan XHS 113

KDP HONDA C-CLASS ULTRA 7X SERIES INTERCHANGEABLE MARINE PROPELLER RUBBER HUB KIT (Aluminum Alloy)
NOTE: Hub Kit for Interchangeable Marine Propeller (HONDA)
SKU #3311

HUB KIT INCLUDES:

• Thrust Washer
• Rubber Hub
• After Spacer

REPLACES / EQUIVALENT TO RUBBER HUB KIT P/N(s):

• SOLAS RBX Hub Kit p/n: RBX-113
• Michigan Hub Kit p/n: XHS 113

KDP ULTRA RUBBER HUB FEATURES:

• Holds up to wide range of Dynamic and Static Loads
• Special formulated rubber compound enabling high power long-term use and cyclic loads
• Excellent vibration and shock-absorbing properties
• High corrosion resistence
• One body construction = conistent daily power loads
• Insert edge design distributes high loads, avoids bending while shifting gears or in the event of propeller striking object
• Resuable if propeller is damaged

KDP INTERCHANGEABLE HUB SPEC INFO
KDP Ultra Rubber Hub Kit p/n: #3311
Used for KDP Propeller Series: Ultra 7X High-Strength Alloy (H.S.A)
Propeller Class: C
Horsepower Range: 25 - 75hp
Hub Type: Interchangeable Rubber Hub
Number of Splines: 13 tooth spline
Insert Material Type: Aluminum Alloy
Made In: South Korea
Outboard Engine(s): HONDA

COMPATIBLE HONDA ENGINE MODEL & YEAR:

ENGINE TYPE	YEAR
BF 35hp	1991 to 1994
BF 40hp	1995 to Newer
BF 45hp	1991 to 1994
BF 50/50A hp	1995 to Newer
BF 60	2010 to Newer

3 BLADE RH ROTATION C CLASS
List of Compatible KDP Ultra 7X Series High-Strength Alloy Interchangeable Outboard Propellers
NOTE: for more information on each item below please go to product page part number

#0315-121-090 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: C
Diameter: 12-1/8"
Pitch: 9"
Gearcase: 3-1/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: 9311-131-09

#0315-116-110 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: C
Diameter: 11-5/8"
Pitch: 11"
Gearcase: 3-1/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: 9311-116-11

#0315-114-120 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: C
Diameter: 11-3/8"
Pitch: 12"
Gearcase: 3-1/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: 9311-114-12

#0315-111-130 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: C
Diameter: 11-1/8"
Pitch: 13"
Gearcase: 3-1/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: 9311-111-13

#0315-111-140 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: C
Diameter: 11-1/8"
Pitch: 14"
Gearcase: 3-1/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: 9311-111-14

#0315-111-150 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: C
Diameter: 11"
Pitch: 15"
Gearcase: 3-1/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: 9311-110-15

#0315-116-120 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: C
Diameter: 11-5/8"
Pitch: 12"
Gearcase: 3-1/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea

#0315-116-130 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: C
Diameter: 11-5/8"
Pitch: 13"
Gearcase: 3-1/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea

#0315-116-140 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: C
Diameter: 11-5/8"
Pitch: 14"
Gearcase: 3-1/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea

#0315-123-150 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: C
Diameter: 12-1/4"
Pitch: 15"
Gearcase: 3-1/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
